LONGi LR4-72HBC-2
370W - 420W
(
210
W/m2
)
First Choice For High-End Residential
High
Efficiency
Leading
Black Module
Efficiency
Class A
Fire Rating
Highest
Fire Safety
Report
Loading
6000/3600Pa
High
Wind
Resistance
LONGi LR4-72HBC-2
370W - 420W
Leading
Black Module
Efficiency
First Choice For High-End Residential
30-Year Warranty for
Extra Linear Power Output
Extra Linear Power Output
15-Year Warranty for
Materials and Processing
Materials and Processing
Define Roof Define Life
LONGi LR4-72HBC-2
Additional Value
25
-Year Power Warranty
Mechanical Parameters
Cell Orientation
108 (6×18)
Junction Box
IP68, three diodes
Output Cable
4mm2, +400, -200mm/±12 00mm
length can be customized
length can be customized
Glass
Frame
Weight
23.5
Dimension
1800×1134×30mm
Packaging
36pcs per pallet / 216pcs per 20' GP / 864pcs per 40' HC
Tolerance:
Length: ±2mm
Width: ±2mm
Electrical Characteristics
STC : AM1.5 1000W/m2 25℃
NOCT : AM1.5 800W/m2 20℃ 1m/s
Test uncertainty for Pmax ±3%
Module Type
Testing Condition
Maximum Power (Pmax/W)
Open Circuit Voltage (Voc/V)
Short Circuit Current (Isc/A)
Voltage at Maximum Power (Vmp/V)
Current at Maximum Power (Imp/A)
Module Efficiency(%)
Electrical characteristics with different rear side power gain
s
Operating Parameters
Operational Temperature
Power Output Tolerance
Maximum System Voltage
Maximum Series Fuse Rating
Nominal Operating Cell Temperature
Protection Class
Fire Rating
-40℃ ~ +85℃
0 ~ 3%
DC1500V (IEC)
30A
45±2℃
Class II
IEC Class C
Mechanical Loading
Front Side Maximum Static Loading
Rear Side Maximum Static Loading
Hailstone Test
5400Pa
2400Pa
25mm Hailstone at the speed of 23m/s
Temperature Ratings (STC)
Temperature Coefficient of Isc
Temperature Coefficient of Voc
Temperature Coefficient of Pmax
+0.050%/℃
Specifications included in this datasheet are subject to change without notice. LONGi reserves the right of final interpretation.
